4 head commercial embroidery machine
4 head commercial embroidery machine 4 head commercial embroidery machine 4 head commercial embroidery machine 4 head commercial embroidery machine 4 head commercial embroidery machine

4 head commercial embroidery machine

Product ID : HM-1504
Product Attributes :

4 head commercial embroidery machine

Item : HM-1504

Frame : t shirt , cap , flat

Needle options : 9/12/15 needles

Working size : 400*400mm 400*300mm

Warranty : 12 monthes

Production time : 7-10 working days

Product Description
Product 4 head commercial embroidery machine
A. General details
Heads  four head
Embroider area  400*300 400*400MM or customized
Max Speed 1200RPM
Needles 9/12 /15 or customized
Net weight  480-600kgs
Packing size  226*120*97cm
Voltage  110-240V
Computer  customized
Power  400-750w
Max no. of memory stitches 100 million
Max no. of memory patterns 800pcs
B. Trims
Hoop /Frames  8*Shirt Hoop 95*95mm
8*Shirt Hoop 145*145mm
8*Shirt Hoop 190*190mm
8*Shirt Hoop 240*240mm
8*Shirt Hoop 2300*238mm
Cap attachment (optional) 8*cap frames
4*cap driver
1*drive of cap frame every machine
Flat attachment 1* flat frame

4 head commercial embroidery machine

4 head commercial embroidery machine achieve the optimal balance of efficiency, precision, flexibility, and return on investment in small-to-medium batch customized production, making them the preferred choice for garment factories, hat factories, cultural and creative studios, and entrepreneurial embroidery workshops.

4 head commercial embroidery machine

4 head commercial embroidery machines represent the mainstream configuration of multi-head computerized embroidery machines, falling between single-head (home/sample) and six/eight-head (large factory production lines). They are specifically designed for medium-sized commercial orders of 50-300 pieces per day. The technology is highly mature, and domestically produced models approach imported levels in stability and embroidery precision, while also possessing stronger localized service responsiveness.

4 head commercial embroidery machine

Core Advantages of 4 head commercial embroidery machine :

1. Highly Efficient Production Capacity: Four heads can operate simultaneously, completing four identical embroidered items in a single setup; efficiency is nearly four times higher than single-head machines, significantly shortening delivery cycles.

2. Flexible Adaptability to Multiple Product Categories: Supports composite techniques such as flat embroidery, towel embroidery, sequin embroidery, and loose bead embroidery (with added modules), easily covering the needs of mainstream commercial products such as T-shirts, baseball caps, canvas bags, and children's clothing.

3. Intelligent operation lowers the barrier to entry: Equipped with a color LCD screen, automatic color changing system, pattern floppy disk/USB reading, zoom/rotate/mirror editing functions, beginners can operate independently after 1-2 days of training.

4. More cost-effective overall of 4 head commercial embroidery machine : Purchase cost is approximately 60%-70% of a six-head machine, requiring less space, and with lower power and maintenance costs.
